Features of XO25D024576GAHE11G
1. Standard 24.576 MHz High-Frequency Reference
24.576 MHz is one of the most widely used high-frequency clock references in digital audio systems (48kHz sampling rate × 512), with irreplaceable significance in audio equipment and video transmission (HDMI/SDI) applications, offering extremely broad compatibility.
2. Wide Supply Voltage Range (1.60~3.63 V)
Supports a wide input voltage from 1.6 V to 3.63 V, compatible with mainstream system supply voltages such as 1.8 V and 3.3 V, offering flexible application.
3. Low Power Consumption (Only 15 mA)
Maintains low power consumption even at 24.576 MHz high-frequency output, ideal for battery-powered and portable devices.
4. Wide Operating Temperature Range (-40~85℃)
Covers the full industrial temperature range, suitable for environments such as automotive electronics and industrial control.
5. Wide Storage Temperature Range (-55~125℃)
Broad storage conditions accommodate wider logistics and warehousing environments.
6. Low Annual Aging (±3 ppm/year)
Outstanding long-term frequency stability, reducing the need for periodic calibration and lowering system maintenance costs.
7. Industry Applications
With its 24.576 MHz standard high-frequency clock (preferred clock reference for digital audio/video), wide supply voltage (1.6~3.63 V), low power consumption (15 mA), -40~85℃ wide operating temperature range, miniature 2520 package, and 10 rigorous reliability tests, the XO25D024576GAHE11G is widely used in digital audio equipment, video transmission interfaces (HDMI/SDI), consumer electronics, communication equipment, automotive electronics, industrial control, IoT terminals, smart meters, and medical devices that require high-frequency stable clock references.
